DAC7563TDSCR TI DAC | 10-WSON (3X3) | 12-Bit, Dual, Low-Power

Product Overview

The DAC7563TDSCR is a dual, 12-bit, low-power, voltage-output digital-to-analog converter (DAC) from Texas Instruments. It operates from a single 2.7V to 5.5V supply and features a 2.5V internal reference (default enabled) with a 0.02% initial accuracy and 5 ppm/°C drift. The device includes a power-on reset circuit that ensures the DAC outputs power up at zero scale and remains there until a valid write to the device occurs. The DAC7563TDSCR uses a 3-wire serial interface (SPI-compatible) that operates at clock rates up to 50 MHz. It is available in a compact 10-pin WSON package (3mm x 3mm) with an exposed thermal pad, making it ideal for space-constrained applications.

Detailed Technical Specifications

Key Features

• Dual 12-bit DAC with low power consumption (0.5 mA per channel at 5V)
• Integrated 2.5V reference with high accuracy and low drift
• Power-on reset to zero scale
• Rail-to-rail output buffer
• 3-wire serial interface compatible with SPI, QSPI, MICROWIRE, and DSP
• Small 10-pin WSON package (3mm x 3mm)
• Extended temperature range: -40°C to +125°C

Target Applications

• 5G base station: Automatic bias control for power amplifiers
• Automotive dashboard: Instrument cluster display calibration
• Industrial process control: Programmable logic controller (PLC) analog output
• Medical equipment: Patient monitoring system setpoint control
• Test and measurement: Arbitrary waveform generation

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for DAC7563TDSCR. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
