NX5P1100UKZ NXP Power Switch IC | 12-WLCSP (1.6x1.3) | 3A, 0.85-5.5V

Product Overview

The NX5P1100UKZ is a high-performance load switch from NXP Semiconductors, designed for power management in portable and compact electronic devices. Housed in a 12-bump WLCSP package measuring 1.6x1.3 mm, this device integrates a low on-resistance N-channel MOSFET with advanced control logic. It supports a wide input voltage range from 0.85 V to 5.5 V and delivers a continuous current of up to 3 A. The NX5P1100UKZ features ultra-low quiescent current, fast turn-on/off times, and built-in protection functions including over-current, over-temperature, and under-voltage lockout. Its small footprint and high efficiency make it ideal for space-constrained applications such as smartphones, tablets, wearables, and IoT modules.

Detailed Technical Specifications

Key Features

• Ultra-low on-resistance (20 mΩ typical) minimizes power loss
• Wide input voltage range (0.85 V to 5.5 V) supports various power rails
• High continuous current capability (3 A) for demanding loads
• Low quiescent current (0.5 µA) extends battery life
• Fast switching times (150 µs on, 10 µs off) for efficient power gating
• Integrated protection: over-current, over-temperature, under-voltage lockout
• Compact 12-WLCSP package saves PCB space

Target Applications

• Smartphones and tablets (e.g., Samsung Galaxy S series, Apple iPad)
• Wearable devices (e.g., Fitbit Charge, Apple Watch)
• IoT modules (e.g., ESP32-based sensors, LoRaWAN gateways)
• Portable medical devices (e.g., glucose monitors, pulse oximeters)
• 5G base station power management modules
• Automotive infotainment and dashboard systems
