LM358PT ST Operational Amplifier | 8-TSSOP | Dual, 1.1MHz, 0.6V/μs

Product Overview

The LM358PT from STMicroelectronics is a dual operational amplifier (op-amp) designed for general-purpose applications. It features a wide supply voltage range from 3V to 30V (or ±1.5V to ±15V), low supply current (0.5mA per amplifier), and a gain bandwidth product of 1.1MHz. The device is housed in a compact 8-TSSOP package, making it suitable for space-constrained designs. With its low input offset voltage (2mV typical) and high input impedance, the LM358PT offers reliable performance in various analog circuits.

Detailed Technical Specifications

Key Features

• Dual operational amplifier in a small 8-TSSOP package
• Wide supply voltage range: 3V to 30V (single) or ±1.5V to ±15V (dual)
• Low supply current: 0.5mA per amplifier
• Low input offset voltage: 2mV typical
• Gain bandwidth product: 1.1MHz
• Slew rate: 0.6V/μs
• Input common-mode voltage range includes ground
• Short-circuit protection
• ESD protection: 2kV HBM

Target Applications

• Sensor signal conditioning in 5G base stations
• Active filters in automotive dashboard displays
• Battery-powered instrumentation
• Audio preamplifiers
• DC gain blocks
• Comparators (with external hysteresis)

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for LM358PT. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.

產品概述

LM358PT 是意法半導體（STMicroelectronics）推出的雙通道運算放大器，適用於通用類比電路。其特點包括寬電源電壓範圍（3V 至 30V 或 ±1.5V 至 ±15V）、低靜態電流（每通道 0.5mA）以及 1.1MHz 的增益頻寬積。器件採用緊湊的 8-TSSOP 封裝，適合空間受限的設計。憑藉低輸入失調電壓（典型值 2mV）和高輸入阻抗，LM358PT 在各種類比電路中提供可靠性能。

詳細技術參數

核心特性

• 雙通道運算放大器，採用小型 8-TSSOP 封裝
• 寬電源電壓範圍：單電源 3V 至 30V 或雙電源 ±1.5V 至 ±15V
• 低靜態電流：每通道 0.5mA
• 低輸入失調電壓：典型值 2mV
• 增益頻寬積：1.1MHz
• 壓擺率：0.6V/μs
• 輸入共模電壓範圍包含地電位
• 短路保護
• ESD 保護：2kV HBM

典型應用場景

• 5G 基站中的感測器訊號調理
• 汽車儀表板顯示器中的主動濾波器
• 電池供電的儀器儀表
• 音頻前置放大器
• 直流增益模塊
• 比較器（需外部遲滯）

環球供應鏈與批發合作夥伴方案

在 Jasin Chip，我們為 LM358PT 提供全面的供應鏈與批發解決方案。 我們的核心優勢包括：

• 全天候環球客戶支援：專業團隊為您提供即時報價及技術支援，無需漫長等待。
• 現貨庫存，即日發貨：確保現貨充足。下午 4 點前確認訂單，即可安排當天寄出。
• 深港聯動，結算靈活：深圳直發全球，物流高效可靠；支援香港銀行戶口轉賬及多幣種結算。
• Escrow 擔保交易：支援 Escrow.com 平台交易，保障買賣雙方權益，小批量訂單亦可安心在線下單。
• BOM 配單與樣板服務：提供樣板測試及認證支援。專注一站式 BOM 配套及緊急缺料採購服務。

品質保證與合規

Jasin Chip 承諾所有出貨產品均為原廠正貨，具備完善的品質保證及產品可追溯性。

• 100% 原廠正貨：承諾所有供應零件均為原裝現貨，品質嚴格把關，來源清晰可追溯。
• 符合 RoHS 認證：所有電子元器件均符合國際環保標準及相關安全認證。
• 原廠封裝保護：嚴格保留原廠原始包裝及封條，確保物流過程中的靜電防護 (ESD) 與物理安全。

以上產品均為原廠正貨，提供 BOM 配單及現貨庫存支援，歡迎查詢。
