STM32L496VGY6PTR ST Microcontrollers | 100-WLCSP (4.62X4.14) | 320KB SRAM, 1MB Flash

Product Overview

The STM32L496VGY6PTR is a high-performance ultra-low-power microcontroller from STMicroelectronics, part of the STM32L4 series. It features an Arm Cortex-M4 core with FPU, operating at up to 80 MHz. This device is designed for applications requiring a balance between performance, power efficiency, and rich connectivity. Packaged in a compact 100-WLCSP (4.62x4.14 mm), it offers a wide range of peripherals including USB OTG, CAN, multiple SPI/I2C/UART interfaces, and advanced analog features. With 1 MB of Flash memory and 320 KB of SRAM, it provides ample storage for complex firmware. The STM32L496VGY6PTR is ideal for battery-powered devices, industrial control, and IoT endpoints.

Detailed Technical Specifications

Key Features

• Ultra-low-power consumption with multiple low-power modes
• Rich connectivity: USB OTG, CAN, SPI, I2C, UART
• Advanced analog: dual 12-bit ADC, dual 12-bit DAC, comparators, op-amps
• Hardware cryptographic acceleration for secure applications
• Large memory: 1 MB Flash, 320 KB SRAM
• Compact 100-WLCSP package for space-constrained designs
• Up to 83 GPIOs for flexible I/O
• Support for external memory interfaces (FMC, Quad-SPI)

Target Applications

• 5G base station control modules
• Automotive dashboard controllers
• Industrial sensors and actuators
• Portable medical devices (e.g., glucose meters)
• Smart home hubs and IoT gateways
• Battery-powered wearables
• Building automation (e.g., HVAC controllers)

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for STM32L496VGY6PTR. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.

產品概述

STM32L496VGY6PTR 是意法半導體（STMicroelectronics）推出的一款高性能超低功耗微控制器，屬於 STM32L4 系列。它採用 Arm Cortex-M4 內核（帶 FPU），最高工作頻率 80 MHz。該器件專為需要平衡性能、功耗和豐富連接性的應用而設計。採用緊湊的 100-WLCSP（4.62x4.14 mm）封裝，提供多種外設，包括 USB OTG、CAN、多個 SPI/I2C/UART 接口以及先進的模擬功能。擁有 1 MB Flash 和 320 KB SRAM，為複雜固件提供充足存儲空間。STM32L496VGY6PTR 非常適合電池供電設備、工業控制和 IoT 終端。

詳細技術參數

核心特性

• 超低功耗，支持多種低功耗模式
• 豐富的連接性：USB OTG、CAN、SPI、I2C、UART
• 先進的模擬功能：雙 12-bit ADC、雙 12-bit DAC、比較器、運算放大器
• 硬件加密加速，適用於安全應用
• 大容量存儲：1 MB Flash、320 KB SRAM
• 緊湊的 100-WLCSP 封裝，適合空間受限的設計
• 最多 83 個 GPIO，靈活的 I/O
• 支持外部存儲器接口（FMC、Quad-SPI）

典型應用場景

• 5G 基站控制模塊
• 汽車儀表盤控制器
• 工業傳感器和執行器
• 便攜式醫療設備（如血糖儀）
• 智能家居中樞和 IoT 網關
• 電池供電的可穿戴設備
• 樓宇自動化（如 HVAC 控制器）

環球供應鏈與批發合作夥伴方案

在 Jasin Chip，我們為 STM32L496VGY6PTR 提供全面的供應鏈與批發解決方案。 我們的核心優勢包括：

• 全天候環球客戶支援：專業團隊為您提供即時報價及技術支援，無需漫長等待。
• 現貨庫存，即日發貨：確保現貨充足。下午 4 點前確認訂單，即可安排當天寄出。
• 深港聯動，結算靈活：深圳直發全球，物流高效可靠；支援香港銀行戶口轉賬及多幣種結算。
• Escrow 擔保交易：支援 Escrow.com 平台交易，保障買賣雙方權益，小批量訂單亦可安心在線下單。
• BOM 配單與樣板服務：提供樣板測試及認證支援。專注一站式 BOM 配套及緊急缺料採購服務。

品質保證與合規

Jasin Chip 承諾所有出貨產品均為原廠正貨，具備完善的品質保證及產品可追溯性。

• 100% 原廠正貨：承諾所有供應零件均為原裝現貨，品質嚴格把關，來源清晰可追溯。
• 符合 RoHS 認證：所有電子元器件均符合國際環保標準及相關安全認證。
• 原廠封裝保護：嚴格保留原廠原始包裝及封條，確保物流過程中的靜電防護 (ESD) 與物理安全。

以上產品均為原廠正貨，提供 BOM 配單及現貨庫存支援，歡迎查詢。
