TSC101CIYLT ST Current Sense Amplifier | SOT-23-5 | 0-28V, 1.5% Accuracy

Product Overview

The TSC101CIYLT is a high-side current sense amplifier from STMicroelectronics, designed for precise current measurement in a wide range of applications. It operates over a common-mode voltage range from 0 to 28 V, making it suitable for both low-side and high-side sensing. The device features a fixed gain of 20 V/V and provides an output voltage proportional to the sensed current. Packaged in a compact SOT-23-5, it is ideal for space-constrained designs.

Detailed Technical Specifications

Key Features

• High-side current sensing up to 28 V
• Fixed gain of 20 V/V eliminates external resistors
• Low offset voltage and gain error for accurate measurement
• Wide supply voltage range: 2.7 V to 26 V
• Low quiescent current: 200 µA typical
• Small SOT-23-5 package saves board space
• Extended temperature range: -40°C to +125°C

Target Applications

• Power management in 5G base stations
• Battery monitoring in electric vehicles (EVs)
• Current sensing in automotive dashboard systems
• Overcurrent protection in industrial motor drives
• Load monitoring in telecom equipment
• Power supply monitoring in servers and data centers

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for TSC101CIYLT. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
