ADS5294IPFP TI ADC | 80-HTQFP (12x12) | 14-Bit, 125MSPS, 8-Channel

Product Overview

The ADS5294IPFP is a high-performance, 14-bit, 125-MSPS, 8-channel analog-to-digital converter (ADC) from Texas Instruments. It is designed for demanding applications requiring high dynamic range and low power consumption. The device integrates eight ADCs in a single 80-pin HTQFP package (12x12 mm), making it ideal for multi-channel data acquisition systems. With a typical power dissipation of only 1.8 W at full speed, it offers an excellent power-to-performance ratio. The ADS5294IPFP features a serial LVDS interface for data output, reducing the number of digital I/O lines. It also includes an internal reference and a sample-and-hold amplifier, simplifying system design.

Detailed Technical Specifications

Key Features

• 14-bit resolution with 125 MSPS sampling rate
• 8 simultaneous sampling channels
• Low power consumption: 1.8 W typical
• Serial LVDS output for reduced pin count
• Internal reference and sample-and-hold
• Excellent dynamic performance: 73.5 dBFS SNR, 85 dBc SFDR
• Small 80-HTQFP package (12x12 mm)
• Industrial temperature range (-40°C to +85°C)

Target Applications

• 5G base station transceivers (e.g., massive MIMO receivers)
• Medical imaging systems (e.g., ultrasound beamforming)
• Radar and electronic warfare systems
• Automotive driver assistance systems (e.g., radar sensors)
• High-speed data acquisition for test and measurement equipment
• Software-defined radios (SDR)

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for ADS5294IPFP. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
