CSD97396Q4MT TI NexFET Power Stage | 8-VSON (3.5x4.5) | 30A, 1MHz

Product Overview

The CSD97396Q4MT is a high-performance NexFET power stage from Texas Instruments, designed for high-current, high-frequency DC-DC converters. It integrates a driver IC and two MOSFETs in a compact 8-VSON (3.5x4.5) package, delivering up to 30A continuous current with excellent thermal performance. This device is optimized for multi-phase buck converters used in servers, telecom, and industrial applications.

Detailed Technical Specifications

Key Features

• Integrated driver and MOSFETs for reduced PCB footprint
• Low on-resistance for high efficiency
• Supports high switching frequency up to 1 MHz
• Thermal enhanced package with exposed pad
• 3.3V and 5V PWM logic compatible
• Under-voltage lockout and over-temperature protection

Target Applications

• Server and datacom power supplies (e.g., 48V to 12V conversion for rack servers)
• Telecom base stations (e.g., 5G massive MIMO power stages)
• Industrial power modules (e.g., motor drives, PLCs)
• Point-of-load converters for FPGA and ASIC (e.g., Xilinx Virtex, Intel Stratix)
• Automotive infotainment and dashboard power (e.g., 12V to 1.8V for SoC)
