DRV8704DCPR TI Motor Driver | 38-HTSSOP | 8.2V-45V, 2.5A

Product Overview

The DRV8704DCPR is a fully integrated dual H-bridge motor driver from Texas Instruments, designed for driving two DC motors or one stepper motor. It operates from a supply voltage range of 8.2V to 45V and can deliver up to 2.5A peak current per channel. The device integrates N-channel power MOSFETs with low RDS(on) for high efficiency, along with current sensing and regulation. It features a simple PWM control interface and includes comprehensive protection features such as overcurrent, overtemperature, and undervoltage lockout.

Detailed Technical Specifications

Key Features

• Dual H-bridge motor driver for two DC motors or one stepper motor
• Wide supply voltage range: 8.2V to 45V
• Low RDS(on) MOSFETs for high efficiency
• Integrated current sensing and regulation
• Simple PWM control interface (IN/IN or PH/EN)
• Protection: overcurrent, overtemperature, undervoltage lockout, fault output
• Small 38-HTSSOP package with exposed pad for thermal dissipation

Target Applications

• 5G base station antenna tilt control
• Automotive dashboard stepper motors
• Industrial automation (conveyor belts, robotic arms)
• Medical equipment (pumps, ventilators)
• Home appliances (washing machines, vacuum cleaners)
• Office automation (printers, scanners)

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for DRV8704DCPR. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
