DRV8824PWP TI Stepper Motor Driver | 28-HTSSOP | 2.5A, 8.2V-45V

Product Overview

The DRV8824PWP from Texas Instruments is a highly integrated stepper motor driver with advanced current regulation and microstepping capabilities. It is designed to drive bipolar stepper motors with up to 2.5 A full-scale current per winding (with proper heat sinking) and operates from 8.2 V to 45 V supply voltage. The device features a simple STEP/DIR interface, adjustable current decay modes, and built-in protection features including overcurrent, overtemperature, and undervoltage lockout. Housed in a compact 28-pin HTSSOP package with an exposed thermal pad, it is ideal for space-constrained applications requiring precise motion control.

Detailed Technical Specifications

Key Features

• Integrated microstepping indexer with up to 1/32 step resolution
• Adjustable current decay modes for optimized performance
• Low RDS(on) for reduced power dissipation
• Simple STEP/DIR control interface
• Built-in 3.3 V regulator for logic supply
• Comprehensive protection: overcurrent, overtemperature, undervoltage lockout
• Small footprint 28-HTSSOP package with exposed pad for thermal management

Target Applications

• 5G base station antenna tilt control
• Automotive dashboard stepper motors (e.g., gauge pointers)
• Industrial automation (e.g., conveyor belt drives, pick-and-place machines)
• Medical equipment (e.g., syringe pumps, patient positioning)
• Office automation (e.g., printer paper feed, scanner mechanisms)
• Robotics (e.g., joint actuation, gripper control)

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for DRV8824PWP. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
