DS90LV049TMT TI LVDS Driver/Receiver | 400Mbps, 3V-3.6V, Dual Channel

Product Overview

The DS90LV049TMT from Texas Instruments is a dual-channel LVDS (Low-Voltage Differential Signaling) driver and receiver designed for high-speed data transmission with low power consumption. It operates at data rates up to 400 Mbps per channel, making it ideal for point-to-point and multi-drop applications. The device features a 3V to 3.6V supply voltage range and is offered in a TSSOP-16 package. It provides robust noise immunity and low electromagnetic interference (EMI), ensuring reliable communication in harsh environments.

Detailed Technical Specifications

Key Features

• Dual-channel LVDS driver and receiver in one package
• Data rates up to 400 Mbps per channel
• Low power consumption: 50 mW typical at 200 MHz
• Wide supply voltage range: 3.0V to 3.6V
• Flow-through pinout for easy PCB layout
• High noise immunity with typical 350 mV output swing
• Receiver input threshold ±100 mV for reliable detection
• Industrial temperature range: -40°C to +85°C
• Compliant with TIA/EIA-644 LVDS standard

Target Applications

The DS90LV049TMT is suitable for a wide range of applications requiring high-speed data transmission with low power and noise. Specific examples include:

• 5G base station backplane communication
• Automotive infotainment and dashboard displays
• Industrial automation and control systems
• Medical imaging equipment
• High-speed data acquisition systems
• Video surveillance and broadcasting
