ISO224BDWVR TI Isolation Amplifier | 8-SOIC | 5kV Isolation, 200kHz Bandwidth

Product Overview

The ISO224BDWVR is a precision isolation amplifier from Texas Instruments, designed for galvanic isolation of analog signals in industrial and automotive applications. It features a reinforced isolation barrier with a withstand voltage of 5 kV RMS, making it suitable for high-voltage environments. The device operates from a single 5V supply and provides a fixed gain of 1. The output is fully differential, enabling direct interface to differential-input ADCs. With a bandwidth of 200 kHz and a typical nonlinearity of 0.01%, it delivers accurate signal reproduction.

Detailed Technical Specifications

Key Features

• Reinforced galvanic isolation up to 5 kV RMS
• High accuracy with 0.01% nonlinearity
• 200 kHz bandwidth for fast signal processing
• Fixed gain of 1 simplifies design
• Differential output reduces noise susceptibility
• Wide operating temperature range
• Low power consumption: 5.5 mA max

Target Applications

• Motor drive current sensing in industrial inverters
• Isolated voltage sensing in 5G base station power supplies
• Battery management systems for electric vehicles
• Isolated data acquisition for dashboard instrumentation
• Solar inverter grid monitoring
