LM25101CSD/NOPB TI Gate Driver | 10-WSON (4x4) | 3A Sink/Source, 100V

Product Overview

The LM25101CSD/NOPB is a high-voltage gate driver from Texas Instruments, designed to drive both high-side and low-side N-channel MOSFETs in synchronous buck or half-bridge configurations. It features a floating high-side driver capable of operating with supply voltages up to 100V, making it suitable for a wide range of power conversion applications. The device provides 3A sink and 3A source drive current, ensuring fast switching and reduced switching losses. Housed in a compact 10-WSON (4x4 mm) package, it offers excellent thermal performance and space savings.

Detailed Technical Specifications

Key Features

• Floating high-side driver up to 100V
• 3A peak sink and source drive current
• Fast propagation delays (26 ns typical)
• Matched propagation delays for high-side and low-side
• Under-voltage lockout (UVLO) for both VDD and VB
• Shutdown input for low power consumption
• Wide operating temperature range
• Compact 10-WSON package with exposed pad for thermal dissipation

Target Applications

• 5G base station power supplies
• Automotive dashboard displays and infotainment systems
• Industrial motor drives and robotics
• Telecom and datacom DC-DC converters
• Solar inverters and battery charging systems
• LED lighting drivers
