SCANSTA111MT TI IEEE 1149.1 Test Bus Controller | 48-TSSOP | 10MHz, 5V

Product Overview

The SCANSTA111MT from Texas Instruments is a high-performance IEEE 1149.1 (JTAG) test bus controller designed for automated test equipment (ATE) and boundary-scan applications. It provides a complete solution for controlling multiple scan chains, enabling efficient testing of complex digital systems. Housed in a compact 48-TSSOP package, this device operates at a maximum clock frequency of 10 MHz and supports a wide supply voltage range of 4.5V to 5.5V. The SCANSTA111MT is ideal for applications requiring robust test access and diagnostics, such as 5G base stations, automotive electronics, and industrial control systems.

Detailed Technical Specifications

Key Features

• Compliant with IEEE 1149.1 standard for boundary-scan testing
• Supports up to 8 independent scan chains for flexible test architecture
• High-speed operation up to 10 MHz for fast test execution
• Wide supply voltage range (4.5V to 5.5V) for compatibility with various systems
• Low power consumption (50 mW typical) for energy-efficient designs
• Compact 48-TSSOP package for space-constrained applications
• Industrial temperature range (-40°C to +85°C) for harsh environments
• Integrated TAP controller with built-in test logic

Target Applications

• 5G Base Stations: Used for testing and diagnostics of RF modules, digital signal processors, and power management units in base station equipment.
• Automotive Electronics: Applied in engine control units (ECUs), advanced driver-assistance systems (ADAS), and infotainment dashboards for boundary-scan testing.
• Industrial Control Systems: Employed in programmable logic controllers (PLCs), motor drives, and robotics for system-level test and debug.
• Telecommunications: Utilized in network switches, routers, and optical transport equipment for JTAG-based testing.
• Medical Devices: Integrated into diagnostic imaging systems and patient monitoring devices for reliable test access.

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for SCANSTA111MT. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
