SN74AHC1G00WDTXRQ1 TI Single 2-Input NAND Gate | 5-X2SON (1.1x0.85) | 2V to 5.5V, -40°C to 125°C

Product Overview

The SN74AHC1G00WDTXRQ1 is a single 2-input NAND gate from Texas Instruments, designed for automotive applications. It operates over a wide supply voltage range of 2V to 5.5V and is specified for the extended industrial temperature range of -40°C to 125°C. The device is housed in a compact 5-pin X2SON package (1.1mm x 0.85mm), making it ideal for space-constrained designs. It features low power consumption, high noise immunity, and balanced propagation delays, ensuring reliable performance in harsh automotive environments.

Detailed Technical Specifications

Key Features

• Single 2-input NAND gate function
• Wide supply voltage range: 2V to 5.5V
• Low power consumption: 10 µA max ICC
• High noise immunity: VNIH = 0.7 × VCC, VNIL = 0.3 × VCC
• Balanced propagation delays: tPLH ≈ tPHL
• Inputs accept voltages up to 5.5V regardless of VCC
• ESD protection exceeds 2000V HBM and 1000V CDM
• Automotive grade: AEC-Q100 qualified
• Ultra-small package: 5-X2SON (1.1mm x 0.85mm)

Target Applications

The SN74AHC1G00WDTXRQ1 is suitable for a wide range of automotive and industrial applications, including:

• 5G base station control logic
• Automotive dashboard displays
• Engine control units (ECUs)
• Body control modules (BCMs)
• Infotainment systems
• Battery management systems (BMS)
• Sensor signal conditioning
• Portable and battery-powered devices

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for SN74AHC1G00WDTXRQ1. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
