SN74ALS1645ANS TI Bus Transceiver | 8-bit | 3-State, Bidirectional

Product Overview

The SN74ALS1645ANS is a high-performance 8-bit bidirectional bus transceiver from Texas Instruments, designed for asynchronous communication between two data buses. It features 3-state outputs and operates with a wide supply voltage range of 4.5V to 5.5V. The device is ideal for driving heavily loaded buses with its high drive capability of up to 48mA sink and 24mA source. Housed in a 20-pin SO package, it offers a compact solution for data flow control in digital systems.

Detailed Technical Specifications

Key Features

• 8-bit bidirectional bus transceiver with 3-state outputs
• High drive capability: IOL = 48mA, IOH = -24mA
• Fast propagation delay: 6.5ns typical
• Wide supply voltage range: 4.5V to 5.5V
• Inputs accept voltages up to 5.5V
• Flow-through pinout for easy PCB layout
• ESD protection exceeds 2000V per MIL-STD-883

Target Applications

• 5G base station control boards for data bus isolation
• Automotive dashboard display systems for signal buffering
• Industrial PLC modules for I/O expansion
• Telecommunications equipment for backplane communication
• Medical imaging devices for data transfer between subsystems
