SN74AS158N-J TI Multiplexer | 4x2:1 | 4.5V-5.5V, 6ns Delay

Product Overview

The SN74AS158N-J is a high-speed quad 2-input multiplexer from Texas Instruments, designed for data selection and routing in digital systems. It features four independent multiplexers, each with two data inputs (A and B) and a common select input (S). The outputs provide the selected data in true (non-inverted) form. This device operates from a single 5V supply and offers fast propagation delays typical of 6ns, making it suitable for high-performance computing and communication systems.

Detailed Technical Specifications

Key Features

• Quad 2-input multiplexer with common select
• Fast propagation delay: 6ns typical
• Low power consumption: 22 mW typical
• Wide operating voltage range: 4.5V to 5.5V
• Input clamp diodes limit high-speed termination effects
• Outputs source/sink 24 mA
• Standard 16-pin DIP package

Target Applications

• Data routing in 5G base stations (e.g., for antenna array control)
• Signal selection in automotive dashboards (e.g., for display mode switching)
• Multiplexing in industrial control systems (e.g., PLC input modules)
• Memory address multiplexing in embedded systems
• General-purpose logic in computing and networking equipment
