SN74AVCAH164245G TI Voltage-Level Translator | 16-bit, 1.2V-3.6V, 100Mbps

Product Overview

The SN74AVCAH164245G is a 16-bit (dual 8-bit) non-inverting bus transceiver from Texas Instruments, designed for asynchronous communication between two data buses. It operates with a supply voltage range of 1.2V to 3.6V on both VCCA and VCCB, making it ideal for voltage-level translation in mixed-voltage systems. The device supports bidirectional data flow with direction control (DIR) and output enable (OE) pins. With a maximum data rate of 100 Mbps and low power consumption, it is suitable for high-speed applications in telecommunications, computing, and industrial systems.

Detailed Technical Specifications

Key Features

• Bidirectional voltage-level translation between 1.2V, 1.5V, 1.8V, 2.5V, and 3.3V nodes
• Non-inverting data paths with separate direction control for each 8-bit channel
• Low static power consumption (ICC < 10 µA)
• Bus hold on data inputs eliminates need for external pull-up resistors
• Partial power-down mode (Ioff) prevents backflow current
• Latch-up performance exceeds 100 mA per JESD 78 Class II

Target Applications

• 5G base station control boards (e.g., interfacing FPGA with baseband processor)
• Automotive dashboard display modules (e.g., connecting MCU to TFT driver)
• Industrial PLC I/O modules (e.g., translating sensor signals to logic levels)
• Networking equipment (e.g., router line card voltage translation)
• Portable electronics (e.g., smartphone peripheral interface)

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for SN74AVCAH164245G. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
