SN74CB3T3245DBQR TI Bus Switch | 20-SSOP | 8-Bit, 2.3-3.6V

Product Overview

The SN74CB3T3245DBQR is a high-performance 8-bit bus switch from Texas Instruments, designed for voltage translation and signal isolation in mixed-voltage systems. Housed in a compact 20-SSOP package, it operates over a wide supply voltage range of 2.3V to 3.6V, making it ideal for low-power and portable applications. The device features bidirectional data flow with near-zero propagation delay, enabling seamless connection between different voltage domains without signal degradation.

Detailed Technical Specifications

Key Features

• Bidirectional voltage translation between 1.8V, 2.5V, and 3.3V logic levels
• Low on-state resistance (5 Ω) minimizes signal distortion
• High bandwidth (100 MHz) supports high-speed data signals
• Near-zero propagation delay (0.25 ns) for real-time switching
• Low power consumption with ICC of 10 μA (max)
• ESD protection up to 2 kV ensures robust operation
• Flow-through pinout simplifies PCB layout

Target Applications

• 5G base stations: Signal routing between baseband processors and RF modules
• Automotive dashboards: Connecting infotainment systems to display panels
• Industrial PLCs: Isolating control signals between different voltage domains
• Portable medical devices: Battery-powered monitors requiring low power
• Networking equipment: Switching between redundant data paths
