SN74CBT16245DGG TI Bus Switch | 16-bit | 5V Tolerant, 4.5ns Propagation Delay

Product Overview

The SN74CBT16245DGG from Texas Instruments is a high-performance 16-bit bus switch designed for bidirectional voltage translation and signal isolation. It features a low on-state resistance of 5 ohms typical, ensuring minimal signal distortion. The device operates over a wide voltage range from 4V to 5.5V and is 5V tolerant on I/O pins, making it ideal for mixed-voltage systems. With a propagation delay of only 4.5ns, it supports high-speed data paths in computing and communication applications.

Detailed Technical Specifications

Key Features

• Bidirectional bus switch with 16-bit width
• Low on-state resistance (5 Ω typical) for minimal signal attenuation
• 5V tolerant I/Os for mixed-voltage compatibility
• Fast propagation delay (4.5 ns max) for high-speed data paths
• Low power consumption with ICC of 3 μA max
• ESD protection exceeds 2000V HBM
• Flow-through pinout for easy PCB layout

Target Applications

• 5G base station control boards for signal routing
• Automotive dashboard infotainment systems
• Industrial PLC I/O modules
• Server and networking equipment (e.g., switch fabric)
• Test and measurement instruments

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for SN74CBT16245DGG. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
