Product Overview

The SN74LV11AD from Texas Instruments is a triple 3-input positive-AND gate designed for 2-V to 5.5-V VCC operation. This device contains three independent 3-input AND gates, each performing the Boolean function Y = A • B • C in positive logic. The SN74LV11AD is fabricated using TI's advanced LinCMOS technology, providing low power consumption and high noise immunity. It is available in a 14-pin SOIC package, making it suitable for space-constrained applications.

Detailed Technical Specifications

Parameter Value
Supply Voltage (VCC) 2 V to 5.5 V
Input Voltage (VI) 0 V to 5.5 V
Output Voltage (VO) 0 V to VCC
High-Level Output Current (IOH) -24 mA at VCC = 5 V
Low-Level Output Current (IOL) 24 mA at VCC = 5 V
Propagation Delay (tpd) 7.5 ns typical at VCC = 5 V, CL = 50 pF
Input Capacitance (Ci) 2 pF typical
Operating Temperature Range -40°C to 125°C
Package 14-SOIC

Key Features

  • Wide operating voltage range: 2 V to 5.5 V
  • High output drive: ±24 mA at 5 V
  • Low power consumption: 10-µA maximum ICC
  • Typical tpd of 7.5 ns at 5 V
  • Inputs accept voltages up to 5.5 V
  • ESD protection exceeds JESD 22
  • Latch-up performance exceeds 250 mA per JESD 78

Target Applications

  • 5G base station control logic
  • Automotive dashboard display control
  • Industrial automation PLC I/O modules
  • Consumer electronics: smart home hubs
  • Medical equipment: patient monitoring systems

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for SN74LV11AD. Our core advantages include:

  • 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
  • In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
  • HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
  • Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
  • BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

  • 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
  • RoHS Compliant: All electronic components comply with international environmental and safety standards.
  • Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
