SN74LVCZ245ANS TI Bus Transceiver | 20-bit | 3.3V, 8mA

Product Overview

The SN74LVCZ245ANS is a 20-bit (dual 10-bit) non-inverting bus transceiver from Texas Instruments, designed for asynchronous bidirectional communication between data buses. It operates from 1.65V to 3.6V, making it ideal for low-voltage applications. The device features 3-state outputs and is part of the LVCZ family, offering high drive capability (up to 24mA at 3.3V) and low power consumption.

Detailed Technical Specifications

Key Features

• Bidirectional bus transceiver with 3-state outputs
• Supports mixed-mode voltage operation (1.65V to 3.6V)
• High drive capability: ±24mA at 3.3V
• Low static power consumption (ICC = 10μA max)
• ESD protection exceeds JESD 22 (2000V HBM)
• Latch-up performance exceeds 100mA per JESD 78

Target Applications

• 5G base station control boards (e.g., data bus isolation between FPGA and processor)
• Automotive dashboard display modules (e.g., connecting MCU to LCD driver)
• Industrial PLC I/O modules (e.g., level translation between 3.3V and 5V logic)
• Networking equipment (e.g., router backplane data transfer)

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for SN74LVCZ245ANS. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
