TL431CD TI Adjustable Precision Shunt Regulator | 8-SOP | 2.495V Ref, 0.5% Accuracy

Product Overview

The TL431CD from Texas Instruments is a three-terminal adjustable shunt regulator with a guaranteed temperature stability over the entire industrial temperature range. This device features a typical output impedance of 0.2 ohms and a reference voltage of 2.495V with an accuracy of 0.5%. The TL431CD is offered in an 8-pin SOP package, making it suitable for space-constrained applications. It operates over a wide current range from 1 mA to 100 mA and can be used as a precision voltage reference, error amplifier, or comparator in various power management circuits.

Detailed Technical Specifications

Key Features

• Precision reference voltage: 2.495 V ±0.5%
• Adjustable output voltage up to 36 V
• Low output impedance: 0.2 Ω typical
• Wide cathode current range: 1 mA to 100 mA
• Temperature compensated for stability
• Low dynamic output impedance
• Available in 8-SOP package for compact designs

Target Applications

• 5G base station power supplies: Used as a precision reference for voltage regulation in remote radio units.
• Automotive dashboard displays: Provides stable voltage reference for LED drivers and display backlighting.
• Industrial control systems: Serves as an error amplifier in isolated DC-DC converters.
• Consumer electronics: Used in battery chargers and power adapters for output voltage regulation.
• Telecommunications equipment: Provides accurate reference for line cards and power modules.
