TLC5942PWP TI LED Driver | 28-HTSSOP | 16-Ch, Dot Correction, PWM Dimming

Product Overview

The TLC5942PWP is a 16-channel constant-current sink LED driver from Texas Instruments, designed for high-precision LED control. It features dot correction (DC) and global brightness control (GBC) via an internal EEPROM, enabling accurate and flexible LED brightness management. The device operates from a 3.0V to 5.5V supply and provides a maximum constant current of 120 mA per channel. Its 28-pin HTSSOP package (PowerPAD) ensures efficient thermal dissipation, making it suitable for demanding applications.

Detailed Technical Specifications

Key Features

• 16 constant-current sink outputs with open/short LED detection
• 6-bit dot correction per channel for color uniformity
• 7-bit global brightness control for overall intensity adjustment
• Internal EEPROM stores correction and brightness settings
• Serial interface with daisy-chain capability for multiple devices
• Thermal shutdown and error detection (LED open/short, overtemperature)
• Low power consumption with sleep mode

Target Applications

• LED video displays (e.g., indoor/outdoor signage panels)
• Automotive lighting (e.g., dashboard backlight, ambient lighting)
• Industrial control panels (e.g., 5G base station status indicators)
• General-purpose LED dimming and color mixing

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for TLC5942PWP. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.

產品概述

TLC5942PWP 是德州儀器推出的16通道恆流沉入式LED驅動器，專為高精度LED控制設計。它通過內部EEPROM實現點校正（DC）和全局亮度控制（GBC），能夠精確靈活地管理LED亮度。器件工作電壓範圍為3.0V至5.5V，每通道最大恆流120 mA。採用28引腳HTSSOP封裝（帶PowerPAD），散熱性能優異，適合要求苛刻的應用。

詳細技術參數

核心特性

• 16路恆流沉入輸出，帶LED開路/短路檢測
• 每通道6位點校正，實現色彩均勻性
• 7位全局亮度控制，調整整體亮度
• 內部EEPROM存儲校正和亮度設置
• 串行接口支持級聯，便於多器件控制
• 熱關斷和錯誤檢測（LED開路/短路、過溫）
• 低功耗，支持睡眠模式

典型應用場景

• LED視頻顯示屏（如室內/室外標牌）
• 汽車照明（如儀表板背光、氛圍燈）
• 工業控制面板（如5G基站狀態指示燈）
• 通用LED調光與混色

環球供應鏈與批發合作夥伴方案

在 Jasin Chip，我們為 TLC5942PWP 提供全面的供應鏈與批發解決方案。 我們的核心優勢包括：

• 全天候環球客戶支援：專業團隊為您提供即時報價及技術支援，無需漫長等待。
• 現貨庫存，即日發貨：確保現貨充足。下午 4 點前確認訂單，即可安排當天寄出。
• 深港聯動，結算靈活：深圳直發全球，物流高效可靠；支援香港銀行戶口轉賬及多幣種結算。
• Escrow 擔保交易：支援 Escrow.com 平台交易，保障買賣雙方權益，小批量訂單亦可安心在線下單。
• BOM 配單與樣板服務：提供樣板測試及認證支援。專注一站式 BOM 配套及緊急缺料採購服務。

品質保證與合規

Jasin Chip 承諾所有出貨產品均為原廠正貨，具備完善的品質保證及產品可追溯性。

• 100% 原廠正貨：承諾所有供應零件均為原裝現貨，品質嚴格把關，來源清晰可追溯。
• 符合 RoHS 認證：所有電子元器件均符合國際環保標準及相關安全認證。
• 原廠封裝保護：嚴格保留原廠原始包裝及封條，確保物流過程中的靜電防護 (ESD) 與物理安全。

以上產品均為原廠正貨，提供 BOM 配單及現貨庫存支援，歡迎查詢。
