TMS470R1B1MPGEA TI 16/32-Bit MCU | 144-LQFP (20x20) | 1MB Flash, 64KB RAM

Product Overview

The TMS470R1B1MPGEA is a high-performance 16/32-bit RISC microcontroller from Texas Instruments, based on the ARM7TDMI core. It operates at up to 60 MHz and features 1 MB of flash memory and 64 KB of RAM. The device is housed in a 144-pin LQFP package with a 20x20 mm footprint, making it suitable for space-constrained applications. It offers a rich set of peripherals including CAN, SPI, SCI, and multiple timers, along with advanced analog features such as dual 10-bit ADCs. Designed for automotive and industrial applications, it provides robust performance and reliability.

Detailed Technical Specifications

Key Features

• ARM7TDMI core with 16/32-bit instruction set
• Up to 60 MHz operation
• 1 MB on-chip flash with ECC
• 64 KB SRAM
• Dual 10-bit ADCs with 16 channels total
• Two CAN 2.0B controllers
• Two SPI and two SCI modules
• Multiple timers including a 32-bit timer
• 8-channel DMA controller
• Low-power modes: idle, sleep, and standby
• Operating temperature range -40°C to +125°C
• 144-pin LQFP package (20x20 mm)

Target Applications

The TMS470R1B1MPGEA is ideal for automotive and industrial applications requiring high reliability and real-time control. Specific examples include:

• Engine control units (ECUs) for automotive
• Transmission control modules
• Anti-lock braking systems (ABS)
• Electric power steering (EPS)
• Industrial motor drives
• Programmable logic controllers (PLCs)
• 5G base station power management
• In-vehicle infotainment systems
• Dashboard controllers

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for TMS470R1B1MPGEA. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
