TPIC46L02DBLE TI Power Management IC | 6-Channel Low-Side Driver, 40V, 1A

Product Overview

The TPIC46L02DBLE is a 6-channel low-side driver from Texas Instruments, designed for automotive and industrial applications requiring high-current switching. It integrates six independent DMOS output transistors with common-source configuration, capable of driving resistive, inductive, or capacitive loads. The device operates from a 5V to 40V supply and delivers up to 1A continuous current per channel. Built-in protection features include overcurrent shutdown, overtemperature warning, and undervoltage lockout, ensuring robust operation in harsh environments.

Detailed Technical Specifications

Key Features

• Six independent low-side DMOS outputs
• Wide supply voltage range: 5V to 40V
• High output current: 1A continuous per channel
• Low on-resistance: 0.5Ω typical
• Integrated protection: overcurrent, overtemperature, undervoltage lockout
• Fast switching: up to 100 kHz
• TTL/CMOS compatible inputs
• Available in SSOP-24 package

Target Applications

• Automotive: LED lighting, solenoid drivers, relay drivers in body control modules (e.g., door locks, window lifts)
• Industrial: Programmable logic controllers (PLCs), motor control for conveyor systems
• Consumer: Appliance control (e.g., washing machine valves, dishwasher solenoids)
• Telecom: Power distribution in 5G base station remote radio units (RRUs)
• Medical: Actuator control in patient monitoring systems
