TPS56100PWP TI Power Management IC | 28-HTSSOP | 1.5A Output, 4.5V-28V Input

Product Overview

The TPS56100PWP is a high-performance, synchronous buck converter from Texas Instruments, designed for efficient power management in a wide range of applications. It integrates a 1.5A, 0.2Ω high-side MOSFET and a 0.2Ω low-side MOSFET, enabling high efficiency and compact design. The device operates over an input voltage range of 4.5V to 28V, making it suitable for systems powered from 5V, 12V, or 24V rails. The output voltage is adjustable from 0.8V to 6V, with a switching frequency of 300kHz to 2MHz, allowing optimization for size and efficiency. The TPS56100PWP is housed in a 28-pin HTSSOP package with PowerPAD for enhanced thermal performance.

Detailed Technical Specifications

Key Features

• Integrated 1.5A MOSFETs for high efficiency
• Wide input voltage range: 4.5V to 28V
• Adjustable output voltage from 0.8V to 6V
• Programmable switching frequency up to 2MHz
• PowerPAD package for excellent thermal dissipation
• Internal soft-start and overcurrent protection
• Hiccup mode for short-circuit protection
• Thermal shutdown protection

Target Applications

• 5G base station power supplies
• Automotive infotainment and dashboard systems
• Industrial control and automation
• Telecommunications equipment
• Point-of-load (POL) converters for FPGAs and DSPs
• Battery-powered systems
