TPS65100PWPR TI PMIC | 24-HTSSOP | Triple Output, 5.5V Input

Product Overview

The TPS65100PWPR from Texas Instruments is a highly integrated power management IC (PMIC) designed for small- to medium-sized TFT-LCD displays. It provides three regulated output voltages: a main output (V_OUT), a gate-on voltage (V_GH), and a gate-off voltage (V_GL). The device operates from a single 2.7V to 5.5V input supply, making it suitable for battery-powered applications. The TPS65100PWPR is housed in a compact 24-pin HTSSOP package with PowerPAD™ for enhanced thermal performance.

Detailed Technical Specifications

Key Features

• Triple output DC-DC converter for TFT-LCD bias supply
• Integrated 1.2 MHz switching regulator for small external components
• High efficiency up to 90%
• Power-save mode for improved efficiency at light loads
• Undervoltage lockout (UVLO) and overcurrent protection
• Thermal shutdown protection
• Small 24-pin HTSSOP package with PowerPAD for thermal dissipation

Target Applications

• Portable navigation devices (PND) and GPS units
• Digital photo frames
• Portable DVD players
• Tablet PCs and e-readers
• Industrial display panels (e.g., 5G base station status displays)
• Automotive dashboard displays
• Medical equipment displays
