TPS7230QP TI Linear Regulator | 8-PDIP | -30V Input, -30V Output, 150mA

Product Overview

The TPS7230QP from Texas Instruments is a negative-voltage, low-dropout (LDO) linear regulator designed for applications requiring a regulated -30V output. Housed in an 8-pin PDIP package, this device offers a simple, cost-effective solution for generating a stable negative rail from a negative input voltage. With an output current capability of 150mA and a dropout voltage of typically 600mV at full load, the TPS7230QP is ideal for powering analog circuits, operational amplifiers, and other sensitive electronics that require a clean negative supply.

Detailed Technical Specifications

Key Features

• Negative voltage regulator with fixed -30V output
• Low dropout voltage: 600mV at 150mA
• Output current up to 150mA
• Wide input voltage range: -4.5V to -30V
• Low quiescent current: 1.5mA
• Excellent line and load regulation
• Built-in overcurrent and thermal protection
• Industry-standard 8-PDIP package for easy prototyping

Target Applications

• 5G base station power management: providing a clean negative rail for RF amplifiers and mixers
• Automotive dashboard displays: powering negative bias for LCD panels
• Industrial sensor interfaces: supplying negative voltage for operational amplifiers in signal conditioning
• Audio equipment: generating a negative supply for high-fidelity audio op-amps
• Test and measurement instruments: stable negative rail for precision analog circuits

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for TPS7230QP. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
