TS5A1066YZPR TI Analog Switch | 5-DSBGA (1.4X0.9) | 10Ω Ron, 1.8V-5.5V

Product Overview

The TS5A1066YZPR is a single-pole single-throw (SPST) analog switch from Texas Instruments, designed for general-purpose switching applications. It features a low on-state resistance of 10Ω (typical) and operates over a wide supply voltage range of 1.8V to 5.5V. The device is housed in a compact 5-DSBGA (1.4mm x 0.9mm) package, making it ideal for space-constrained designs. It offers bidirectional signal switching with low power consumption and high ESD protection (2kV HBM).

Detailed Technical Specifications

Key Features

• Low on-state resistance (10Ω typical) minimizes signal distortion
• Wide supply voltage range (1.8V to 5.5V) supports various logic levels
• High bandwidth (100 MHz) suitable for analog and digital signals
• Ultra-low power consumption (0.1 μA typical) extends battery life
• ESD protection up to 2 kV HBM ensures robustness
• Compact 5-DSBGA package saves PCB space
• Bidirectional signal switching with break-before-make operation

Target Applications

• 5G base station: Signal routing in RF control circuits
• Automotive dashboard: Audio signal switching and sensor interface
• Portable electronics: Audio jack detection and power management
• Industrial automation: Analog signal multiplexing in PLCs
• Medical devices: ECG signal switching and data acquisition

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for TS5A1066YZPR. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
