TXS0108EDGSR TI 8-Bit Bidirectional Voltage-Level Translator | 20-VSSOP | 1.65V-3.6V, 100Mbps

Product Overview

The TXS0108EDGSR is a 8-bit bidirectional voltage-level translator from Texas Instruments, designed for applications requiring voltage translation between different logic levels. It operates over a wide voltage range from 1.65V to 3.6V on both A and B ports, supporting data rates up to 100 Mbps. The device is housed in a compact 20-VSSOP package, making it ideal for space-constrained designs. It features automatic direction sensing, eliminating the need for direction control signals, and provides excellent ESD protection up to 8 kV (HBM).

Detailed Technical Specifications

Key Features

• Bidirectional voltage translation without direction pin
• Supports mixed-mode voltage operation: 1.8V, 2.5V, 3.3V, and 5V (with VCCB up to 3.6V)
• High data rate up to 100 Mbps
• Low quiescent current (10 µA typical)
• Power-off high-impedance outputs
• ESD protection exceeds JESD 22

Target Applications

• 5G base station control boards (e.g., translating between 1.8V FPGA and 3.3V microcontroller)
• Automotive dashboard displays (e.g., connecting 1.8V sensor to 3.3V processor)
• Industrial PLC modules (e.g., level translation for I/O interfaces)
• Consumer electronics (e.g., smartphone accessory communication)
• IoT gateways (e.g., bridging different voltage domains)

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for TXS0108EDGSR. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
