TXS0206-29YFPRB TI Voltage Level Translator | 20-DSBGA | 1.1V-3.6V, 100Mbps

Product Overview

The TXS0206-29YFPRB is a 6-bit bidirectional voltage-level translator from Texas Instruments, designed for open-drain and push-pull applications. It operates over a wide voltage range from 1.1V to 3.6V on both the A and B ports, making it ideal for multi-voltage systems. The device features automatic direction sensing, eliminating the need for a direction control pin. Housed in a compact 20-DSBGA package (0.4mm pitch), it supports high-speed data rates up to 100 Mbps, ensuring seamless communication between different voltage domains.

Detailed Technical Specifications

Key Features

• Bidirectional voltage translation without direction pin
• Supports open-drain and push-pull outputs
• Low quiescent current (1.5 µA typical)
• High drive strength: ±24 mA at 3.3V
• Glitch-free power-up sequencing
• Ultra-small package for space-constrained designs

Target Applications

• 5G base stations: Level translation between baseband processor (1.8V) and RF front-end (3.3V)
• Automotive dashboard: Interface between microcontroller (3.3V) and display module (1.8V)
• Industrial sensors: Connect low-voltage sensor (1.2V) to PLC (3.3V)
• Portable electronics: Battery management IC (1.8V) to application processor (3.3V)
• Networking equipment: FPGA (1.8V) to Ethernet PHY (2.5V)
