STM8AF6223PDU ST Microcontroller | 20-TSSOP | 8-bit, 8KB Flash, LIN

Product Overview

The STM8AF6223PDU is an 8-bit microcontroller from STMicroelectronics' STM8A automotive series, designed for reliable performance in harsh environments. Housed in a compact 20-TSSOP package, it integrates an 8-bit core with up to 8 KB of Flash memory, 640 bytes of RAM, and 128 bytes of EEPROM. Operating at a frequency of up to 16 MHz, it offers a rich set of peripherals including LIN (Local Interconnect Network) interface, 10-bit ADC, timers, and I2C/SPI communication. This device is AEC-Q100 qualified, making it suitable for automotive applications such as body control modules, sensor interfaces, and actuator control.

Detailed Technical Specifications

Key Features

• High-performance 8-bit core with single-cycle multiplication
• Embedded LIN controller for automotive networking
• Up to 16 MHz CPU clock with low power consumption
• Wide operating voltage range (3.0V to 5.5V)
• Enhanced ESD protection and EMI robustness
• Integrated EEPROM for data storage
• 10-bit ADC with up to 7 multiplexed channels
• Multiple communication interfaces (I2C, SPI, UART)
• Advanced 16-bit timer with PWM generation
• Watchdog timer and brown-out reset

Target Applications

• Automotive body control modules (e.g., door control unit, window lift)
• LIN-based sensor interfaces (e.g., rain sensor, light sensor)
• Actuator control for HVAC systems
• Dashboard and instrument cluster controllers
• 5G base station power management and monitoring
• Industrial automation sensors and actuators

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for STM8AF6223PDU. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
