STM8L152K6T6 ST Microcontroller | 32-LQFP (7x7) | 32MHz, 32KB Flash, 2KB RAM

Product Overview

The STM8L152K6T6 is a low-power 8-bit microcontroller from STMicroelectronics, part of the STM8L series. It features an advanced STM8 core operating at up to 32 MHz, with 32 KB of Flash memory and 2 KB of RAM. The device is housed in a compact 32-LQFP (7x7 mm) package, making it suitable for space-constrained applications. It offers a rich set of peripherals including multiple timers, communication interfaces (SPI, I2C, USART), and analog features such as a 12-bit ADC and DAC. The STM8L152K6T6 is designed for ultra-low-power consumption, with multiple low-power modes, making it ideal for battery-powered and energy-efficient applications.

Detailed Technical Specifications

Key Features

• Ultra-low-power consumption: 0.5 µA in Halt mode, 1.5 µA in Active-Halt mode
• Fast wake-up from low-power modes (less than 5 µs)
• Embedded 32 kHz and 16 MHz oscillators
• Up to 26 I/Os with interrupt capability
• Dual-sampling ADC for accurate measurements
• Embedded EEPROM emulation
• SWIM single-wire debug interface

Target Applications

The STM8L152K6T6 is ideal for a wide range of low-power and cost-sensitive applications, including:

• Portable medical devices (e.g., blood glucose meters, thermometers)
• Smart home sensors (e.g., temperature/humidity sensors, motion detectors)
• Industrial control systems (e.g., PLC I/O modules, sensor interfaces)
• Consumer electronics (e.g., remote controls, smart watches)
• Automotive body electronics (e.g., window lift control, lighting modules)
• 5G base station monitoring and control units
• Dashboard displays and instrument clusters

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for STM8L152K6T6. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.

產品概述

STM8L152K6T6 是意法半導體（STMicroelectronics）推出的一款低功耗8位微控制器，屬於 STM8L 系列。它採用先進的 STM8 內核，最高工作頻率可達 32 MHz，配備 32 KB 閃存和 2 KB RAM。該器件採用緊湊的 32-LQFP（7x7 mm）封裝，適合空間受限的應用。它提供豐富的外設，包括多個定時器、通信接口（SPI、I2C、USART）以及模擬功能（如12位ADC和DAC）。STM8L152K6T6 專為超低功耗設計，具有多種低功耗模式，非常適合電池供電和節能應用。

詳細技術參數

核心特性

• 超低功耗：暫停模式 0.5 µA，活躍暫停模式 1.5 µA
• 從低功耗模式快速喚醒（小於 5 µs）
• 內置 32 kHz 和 16 MHz 振盪器
• 最多 26 個可中斷 I/O 口
• 雙採樣 ADC 實現精確測量
• 內嵌 EEPROM 模擬
• SWIM 單線調試接口

典型應用場景

STM8L152K6T6 適用於各種低功耗和成本敏感的應用，包括：

• 便攜式醫療設備（如血糖儀、體溫計）
• 智能家居傳感器（如溫濕度傳感器、運動檢測器）
• 工業控制系統（如 PLC I/O 模塊、傳感器接口）
• 消費電子產品（如遙控器、智能手錶）
• 汽車車身電子（如車窗升降控制、照明模塊）
• 5G 基站監控與控制單元
• 儀表盤顯示與儀表組

環球供應鏈與批發合作夥伴方案

在 Jasin Chip，我們為 STM8L152K6T6 提供全面的供應鏈與批發解決方案。 我們的核心優勢包括：

• 全天候環球客戶支援：專業團隊為您提供即時報價及技術支援，無需漫長等待。
• 現貨庫存，即日發貨：確保現貨充足。下午 4 點前確認訂單，即可安排當天寄出。
• 深港聯動，結算靈活：深圳直發全球，物流高效可靠；支援香港銀行戶口轉賬及多幣種結算。
• Escrow 擔保交易：支援 Escrow.com 平台交易，保障買賣雙方權益，小批量訂單亦可安心在線下單。
• BOM 配單與樣板服務：提供樣板測試及認證支援。專注一站式 BOM 配套及緊急缺料採購服務。

品質保證與合規

Jasin Chip 承諾所有出貨產品均為原廠正貨，具備完善的品質保證及產品可追溯性。

• 100% 原廠正貨：承諾所有供應零件均為原裝現貨，品質嚴格把關，來源清晰可追溯。
• 符合 RoHS 認證：所有電子元器件均符合國際環保標準及相關安全認證。
• 原廠封裝保護：嚴格保留原廠原始包裝及封條，確保物流過程中的靜電防護 (ESD) 與物理安全。

以上產品均為原廠正貨，提供 BOM 配單及現貨庫存支援，歡迎查詢。
