STM8S003K3T6CTR ST Microcontroller | 32-LQFP（7X7） | 8-bit, 8KB Flash, 16MHz

Product Overview

The STM8S003K3T6CTR is an 8-bit microcontroller from STMicroelectronics' STM8S series, designed for cost-sensitive applications requiring robust performance. It features an advanced STM8 core operating at up to 16 MHz, 8 KB of Flash memory, 1 KB of RAM, and 128 bytes of EEPROM. Housed in a compact 32-LQFP (7x7 mm) package, it offers a rich set of peripherals including UART, SPI, I2C, timers, and a 10-bit ADC. This device is ideal for industrial control, consumer electronics, and automotive body applications.

Detailed Technical Specifications

Key Features

• High-performance STM8 core with Harvard architecture and 3-stage pipeline
• Up to 16 MIPS throughput at 16 MHz
• Embedded single-wire debug module (SWIM)
• Clock sources: internal 16 MHz RC, external crystal, or resonator
• Reset circuitry: power-on reset (POR), brown-out reset (BOR)
• Low power modes: Wait, Active Halt, Halt
• Up to 28 I/Os with programmable pull-up and interrupt capability
• 10-bit ADC with up to 5 multiplexed channels
• Two 16-bit timers with input capture, output compare, and PWM
• One 8-bit timer with prescaler
• UART with synchronous mode and LIN support
• SPI interface up to 8 Mbit/s
• I2C interface up to 400 kHz
• 128 bytes of data EEPROM with write/erase cycles
• 96-bit unique ID for traceability

Target Applications

The STM8S003K3T6CTR is suitable for a wide range of applications including: 5G base station power management, automotive dashboard controllers, industrial sensor interfaces, home appliance control (e.g., washing machines, air conditioners), battery management systems, and consumer electronics like smart toys and remote controls.

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for STM8S003K3T6CTR. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.

產品概述

STM8S003K3T6CTR 是意法半導體 STM8S 系列的一款 8 位微控制器，專為成本敏感的應用而設計，具有強大的性能。它採用先進的 STM8 內核，工作頻率高達 16 MHz，配備 8 KB 閃存、1 KB RAM 和 128 字節 EEPROM。封裝為緊湊的 32-LQFP（7x7 mm），提供豐富的外設，包括 UART、SPI、I2C、定時器和 10 位 ADC。該器件非常適合工業控制、消費電子和汽車車身應用。

詳細技術參數

核心特性

• 高性能 STM8 內核，哈佛架構，3級流水線
• 16 MHz 下高達 16 MIPS 吞吐量
• 嵌入式單線調試模塊 (SWIM)
• 時鐘源：內部 16 MHz RC，外部晶體或諧振器
• 復位電路：上電復位 (POR)，欠壓復位 (BOR)
• 低功耗模式：等待、活躍停機、停機
• 最多 28 個 I/O，可編程上拉和中斷功能
• 10位 ADC，最多 5 個多路復用通道
• 兩個 16 位定時器，帶輸入捕獲、輸出比較和 PWM
• 一個 8 位定時器，帶預分頻器
• UART，支持同步模式和 LIN
• SPI 接口，最高 8 Mbit/s
• I2C 接口，最高 400 kHz
• 128 字節數據 EEPROM，支持寫/擦循環
• 96 位唯一 ID，用於可追溯性

典型應用場景

STM8S003K3T6CTR 適用於多種應用，包括：5G 基站電源管理、汽車儀表盤控制器、工業傳感器接口、家用電器控制（如洗衣機、空調）、電池管理系統以及消費電子產品，如智能玩具和遙控器。

環球供應鏈與批發合作夥伴方案

在 Jasin Chip，我們為 STM8S003K3T6CTR 提供全面的供應鏈與批發解決方案。 我們的核心優勢包括：

• 全天候環球客戶支援：專業團隊為您提供即時報價及技術支援，無需漫長等待。
• 現貨庫存，即日發貨：確保現貨充足。下午 4 點前確認訂單，即可安排當天寄出。
• 深港聯動，結算靈活：深圳直發全球，物流高效可靠；支援香港銀行戶口轉賬及多幣種結算。
• Escrow 擔保交易：支援 Escrow.com 平台交易，保障買賣雙方權益，小批量訂單亦可安心在線下單。
• BOM 配單與樣板服務：提供樣板測試及認證支援。專注一站式 BOM 配套及緊急缺料採購服務。

品質保證與合規

Jasin Chip 承諾所有出貨產品均為原廠正貨，具備完善的品質保證及產品可追溯性。

• 100% 原廠正貨：承諾所有供應零件均為原裝現貨，品質嚴格把關，來源清晰可追溯。
• 符合 RoHS 認證：所有電子元器件均符合國際環保標準及相關安全認證。
• 原廠封裝保護：嚴格保留原廠原始包裝及封條，確保物流過程中的靜電防護 (ESD) 與物理安全。

以上產品均為原廠正貨，提供 BOM 配單及現貨庫存支援，歡迎查詢。
