ADS4146IRGZT TI ADC | 48-VQFN (7x7) | 14-Bit, 160 MSPS, LVDS

Product Overview

The ADS4146IRGZT is a high-performance 14-bit, 160 MSPS analog-to-digital converter (ADC) from Texas Instruments. It features a low-power architecture with excellent dynamic performance, making it ideal for demanding applications such as wireless communications, test and measurement, and radar systems. The device operates from a single 1.8-V supply and includes an internal reference and sample-and-hold circuit. The digital output is LVDS-compatible, reducing the number of I/O lines. The ADS4146IRGZT is available in a compact 48-pin VQFN (7x7 mm) package.

Detailed Technical Specifications

Key Features

• 14-bit resolution with 160 MSPS sampling rate
• Low power consumption: 1.1 W at 160 MSPS
• Excellent dynamic performance: 73.5 dBc SNR at 100 MHz IF
• SFDR: 85 dBc at 100 MHz IF
• Internal reference and sample-and-hold
• LVDS output interface
• Programmable gain and offset
• Power-down and standby modes
• Small 48-pin VQFN package (7x7 mm)

Target Applications

• Wireless communications: 5G base stations, software-defined radios
• Test and measurement: oscilloscopes, spectrum analyzers
• Radar systems: phased array radar, automotive radar
• Medical imaging: ultrasound, MRI
• Industrial: high-speed data acquisition

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for ADS4146IRGZT. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
