DAC904E TI Digital-to-Analog Converter | 28-TSSOP | 14-Bit, 165 MSPS

Product Overview

The DAC904E is a high-performance, 14-bit digital-to-analog converter (DAC) from Texas Instruments, offering a sampling rate of up to 165 MSPS. Housed in a compact 28-pin TSSOP package, it is designed for demanding applications requiring high speed and precision. The device features a current output architecture with a nominal full-scale output current of 20 mA, and supports both single-ended and differential outputs. Its low glitch energy and excellent spurious-free dynamic range (SFDR) make it ideal for communication systems and waveform generation.

Detailed Technical Specifications

Key Features

• 14-bit resolution with 165 MSPS update rate
• Low glitch energy: 3 pV-s
• Excellent SFDR: 75 dBc at 10 MHz output
• Internal reference with 20 mA full-scale current
• Single 3V or 5V supply operation
• Power dissipation: 170 mW at 5V
• Pin-compatible with 12-bit DAC902 and 10-bit DAC900

Target Applications

• Wireless communication systems: 5G base stations, software-defined radios
• Arbitrary waveform generation (AWG) for test equipment
• Medical imaging: ultrasound systems
• Instrumentation: spectrum analyzers, signal generators
• Industrial control: high-speed data acquisition

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for DAC904E. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
