JM38510/13003BEA TI Logic Gates | DIP-14 | 4.5V-5.5V, 2-Input NAND

Product Overview

The JM38510/13003BEA is a high-reliability quad 2-input NAND gate from Texas Instruments, manufactured in compliance with MIL-STD-883 and JAN (Joint Army-Navy) specifications. This device is part of the 54LS00 series, offering low-power Schottky technology for high-speed logic operations. It is designed for use in military, aerospace, and industrial applications where stringent quality and performance standards are required. The device is housed in a 14-pin DIP (Dual In-line Package) and operates over the full military temperature range of -55°C to +125°C.

Detailed Technical Specifications

Key Features

• Quad 2-input NAND gate logic function
• Low-power Schottky technology for high speed and low power consumption
• MIL-STD-883 compliant for high reliability
• JAN (JM38510) qualified for military applications
• Wide operating temperature range: -55°C to +125°C
• Standard 14-pin DIP package for easy integration
• Input clamp diodes to limit ringing and overshoot
• Direct interface with TTL logic levels

Target Applications

• Military communication systems (e.g., AN/PRC-117G radio)
• Aerospace avionics (e.g., flight control computers in F-16)
• Industrial control systems (e.g., PLC modules for factory automation)
• 5G base station control logic (e.g., signal processing boards)
• Automotive dashboard electronics (e.g., instrument cluster logic)
• Medical equipment (e.g., patient monitoring systems)

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for JM38510/13003BEA. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
