JM38510/30605BDA TI Logic Gates | DIP | Quad 2-Input NAND, 4.5V-5.5V

Product Overview

The JM38510/30605BDA is a high-reliability quad 2-input NAND gate from Texas Instruments, manufactured in compliance with MIL-STD-883 and JAN (Joint Army-Navy) specifications. This device is part of the 54LS00 series, offering low-power Schottky technology with typical propagation delay of 9.5 ns and power dissipation of 2 mW per gate. It is designed for operation over the full military temperature range (-55°C to +125°C) and is available in a 14-pin ceramic DIP package. The JM38510/30605BDA is ideal for applications requiring high reliability and performance in harsh environments.

Detailed Technical Specifications

Key Features

• Quad 2-input NAND gate functionality
• Low-power Schottky technology for high speed and low power
• Full military temperature range operation
• Hermetic ceramic DIP package for enhanced reliability
• Compliant with MIL-STD-883 and JAN specifications
• Direct replacement for standard 54LS00 devices

Target Applications

• Military and aerospace electronics (e.g., avionics control systems, radar signal processing)
• Industrial control systems (e.g., PLCs, motor drives)
• Communication infrastructure (e.g., 5G base station control logic, satellite communication systems)
• Automotive electronics (e.g., engine control units, dashboard logic)
• Medical devices (e.g., patient monitoring systems, diagnostic equipment)

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for JM38510/30605BDA. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
