JM38510/66302B2A TI Logic Gates | 20-LCCC (8.89X8.89) | 4.5V-5.5V, 4 Gates

Product Overview

The JM38510/66302B2A is a high-reliability quad 2-input NAND gate from Texas Instruments, designed for military and aerospace applications. Housed in a 20-lead ceramic leadless chip carrier (LCCC) package measuring 8.89x8.89 mm, this device operates over the full military temperature range (-55°C to +125°C). It features standard TTL logic levels with a supply voltage of 4.5V to 5.5V, providing robust performance in harsh environments.

Detailed Technical Specifications

Key Features

• Quad 2-input NAND gate logic function
• Military-grade reliability: JAN (JM38510) qualified
• Wide operating temperature range: -55°C to +125°C
• Standard TTL compatible inputs and outputs
• Hermetic ceramic package for harsh environments
• Low power consumption: 22 mW typical per gate
• High noise immunity: 0.4V typical

Target Applications

• Avionics control systems (e.g., flight management computers)
• Military communication equipment (e.g., encrypted radios)
• Satellite payload data processing
• Industrial automation with extended temperature requirements
• 5G base station control logic (e.g., antenna tilt controllers)
• Automotive engine control units (ECUs) for off-road vehicles

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for JM38510/66302B2A. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
