LP5810BYBHR TI LED Driver | 9-DSBGA (1.43x1.43) | 4-Channel, I2C, 1.8V Logic

Product Overview

The LP5810BYBHR is a high-performance, 4-channel LED driver from Texas Instruments, designed for portable and compact applications. Housed in a tiny 9-DSBGA (1.43x1.43 mm) package, it integrates I2C-controlled constant current sinks with programmable brightness and blinking patterns. Operating from a 1.8V logic supply, it supports up to 25 mA per channel with low dropout voltage, making it ideal for battery-powered devices. The device features automatic power-save mode, thermal shutdown, and under-voltage lockout, ensuring reliable operation in space-constrained designs.

Detailed Technical Specifications

Key Features

• 4 independent constant current sinks with 8-bit PWM dimming
• I2C interface for individual channel control
• Ultra-small 9-DSBGA package saves board space
• Low dropout voltage (100 mV at 20 mA)
• Automatic power-save mode reduces current consumption
• Thermal shutdown and under-voltage lockout protection
• 1.8V logic compatible for low-voltage systems

Target Applications

• Smartphone notification LEDs
• Wearable device indicators (e.g., fitness trackers, smartwatches)
• Portable medical devices (e.g., pulse oximeters, glucose monitors)
• IoT sensor modules with status LEDs
• Battery-powered remote controls
• Small form-factor display backlighting

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for LP5810BYBHR. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
