LP8556TMX-E05/NOPB TI LED Driver | 20-DSBGA (2.04X1.78) | 6-Channel, 40V

Product Overview

The LP8556TMX-E05/NOPB is a high-efficiency, 6-channel LED driver from Texas Instruments, designed for backlighting applications in LCD displays. It integrates a boost converter and current sinks to drive up to 6 strings of LEDs with excellent current matching. The device operates from a 2.7V to 20V input voltage range and can boost up to 40V, making it suitable for a wide range of display sizes. The LP8556 features PWM dimming with a 30kHz frequency, programmable via I2C interface, and includes advanced fault protection such as overvoltage, overcurrent, and thermal shutdown.

Detailed Technical Specifications

Key Features

• 6-channel LED driver with integrated boost converter
• High efficiency up to 90%
• Programmable LED current and dimming via I2C
• Excellent current matching for uniform brightness
• Small 20-DSBGA package saves board space
• Comprehensive fault protection

Target Applications

• LCD backlighting for tablets, notebooks, and monitors
• Automotive display backlighting (e.g., dashboard, infotainment)
• Industrial display panels
• 5G base station status indicators
• Portable medical devices

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for LP8556TMX-E05/NOPB. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
