MSC1214Y4PAGT TI Precision ADC | 64-TQFP (10x10) | 24-Bit, 4-Ch, 1kSPS

Product Overview

The MSC1214Y4PAGT from Texas Instruments is a high-precision, low-power, 24-bit delta-sigma analog-to-digital converter (ADC) with an integrated microcontroller core. Housed in a compact 64-pin TQFP (10x10 mm) package, it combines a 4-channel differential input multiplexer, programmable gain amplifier (PGA), and a 8051-compatible microprocessor, making it ideal for demanding measurement and control applications.

Detailed Technical Specifications

Key Features

• High-resolution 24-bit delta-sigma ADC with low noise (2.5 µVpp)
• On-chip 8051-compatible microcontroller with 8 kB Flash and 256 B RAM
• Programmable gain amplifier (PGA) with gains from 1 to 128
• Internal voltage reference with low drift (5 ppm/°C)
• SPI and UART serial interfaces for flexible communication
• Low power consumption: 4.5 mW at 3V operation
• Wide operating temperature range: -40°C to +125°C

Target Applications

• Industrial process control (e.g., temperature, pressure, flow transmitters)
• Precision instrumentation (e.g., digital multimeters, data loggers)
• Medical devices (e.g., patient monitoring, diagnostic equipment)
• Smart sensors for IoT and edge computing
• 5G base station power monitoring and control
• Automotive dashboard sensors (e.g., battery voltage, current sensing)
