PCM3052ARTFR TI Audio Codec | 32-VQFN (6.2x5.2) | 24-bit, 96kHz

Product Overview

The PCM3052ARTFR is a high-performance, low-power stereo audio codec from Texas Instruments, designed for portable and embedded audio applications. It integrates a 24-bit stereo ADC and DAC with sampling rates up to 96 kHz, providing excellent audio quality. The device operates from a single 1.8V supply and features a flexible serial audio interface. Housed in a compact 32-VQFN (6.2x5.2 mm) package, it is ideal for space-constrained designs.

Detailed Technical Specifications

Key Features

• 24-bit stereo ADC and DAC with 96 kHz sampling
• Low power consumption: 18 mW playback, 22 mW record
• Single 1.8V digital supply with 3.3V analog supply
• Programmable gain amplifier (PGA) for microphone input
• Digital volume control with soft ramp
• Flexible serial audio interface (I2S, left/right-justified, DSP)
• Built-in high-pass filter for DC offset removal
• Power-down and mute modes
• Compact 32-VQFN package (6.2x5.2 mm)

Target Applications

• Portable audio devices (smartphones, tablets)
• Voice communication systems (VoIP phones, conference systems)
• Automotive infotainment (head units, hands-free kits)
• Industrial audio processing (intercoms, public address systems)
• Consumer electronics (digital cameras, portable media players)
• IoT audio endpoints (smart speakers, voice assistants)

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for PCM3052ARTFR. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.

產品概述

PCM3052ARTFR 是德州儀器（TI）推出的一款高性能、低功耗立體聲音頻編解碼器，專為便攜式和嵌入式音頻應用設計。它集成了 24 位立體聲 ADC 和 DAC，支持高達 96 kHz 的採樣率，提供卓越的音質。該器件可在單一 1.8V 電源下工作，並具有靈活的串行音頻接口。採用緊湊的 32-VQFN（6.2x5.2 mm）封裝，適合空間受限的設計。

詳細技術參數

核心特性

• 24 位立體聲 ADC 和 DAC，支持 96 kHz 採樣
• 低功耗：播放 18 mW，錄音 22 mW
• 單一 1.8V 數字電源，3.3V 模擬電源
• 麥克風輸入可編程增益放大器（PGA）
• 帶軟斜坡的數字音量控制
• 靈活的串行音頻接口（I2S、左/右對齊、DSP）
• 內置高通濾波器，用於直流偏移消除
• 掉電和靜音模式
• 緊湊的 32-VQFN 封裝（6.2x5.2 mm）

典型應用場景

• 便攜式音頻設備（智能手機、平板電腦）
• 語音通信系統（VoIP 電話、會議系統）
• 汽車信息娛樂（主機、免提套件）
• 工業音頻處理（對講機、公共廣播系統）
• 消費電子產品（數碼相機、便攜式媒體播放器）
• 物聯網音頻終端（智能音箱、語音助手）

環球供應鏈與批發合作夥伴方案

在 Jasin Chip，我們為 PCM3052ARTFR 提供全面的供應鏈與批發解決方案。 我們的核心優勢包括：

• 全天候環球客戶支援：專業團隊為您提供即時報價及技術支援，無需漫長等待。
• 現貨庫存，即日發貨：確保現貨充足。下午 4 點前確認訂單，即可安排當天寄出。
• 深港聯動，結算靈活：深圳直發全球，物流高效可靠；支援香港銀行戶口轉賬及多幣種結算。
• Escrow 擔保交易：支援 Escrow.com 平台交易，保障買賣雙方權益，小批量訂單亦可安心在線下單。
• BOM 配單與樣板服務：提供樣板測試及認證支援。專注一站式 BOM 配套及緊急缺料採購服務。

品質保證與合規

Jasin Chip 承諾所有出貨產品均為原廠正貨，具備完善的品質保證及產品可追溯性。

• 100% 原廠正貨：承諾所有供應零件均為原裝現貨，品質嚴格把關，來源清晰可追溯。
• 符合 RoHS 認證：所有電子元器件均符合國際環保標準及相關安全認證。
• 原廠封裝保護：嚴格保留原廠原始包裝及封條，確保物流過程中的靜電防護 (ESD) 與物理安全。

以上產品均為原廠正貨，提供 BOM 配單及現貨庫存支援，歡迎查詢。
