SN74ABT2240N TI Buffer/Driver | 8-Ch, Non-Inverting, 3-State

Product Overview

The SN74ABT2240N from Texas Instruments is an octal buffer and line driver designed for high-performance memory and bus-oriented systems. It features 8-bit non-inverting outputs with 3-state capability, allowing for efficient bus isolation and data flow control. Operating from a 4.5V to 5.5V supply, this device provides high drive capability (up to 64mA sink/32mA source) while maintaining low power consumption. The SN74ABT2240N is available in a 20-pin PDIP package, making it suitable for through-hole PCB assembly.

Detailed Technical Specifications

Key Features

• High drive capability: 64mA sink, 32mA source
• 3-state outputs for bus-oriented applications
• Low power consumption with advanced BiCMOS technology
• ESD protection exceeds 2000V per MIL-STD-883
• Latch-up performance exceeds 500mA per JEDEC JESD-17
• Package options: PDIP, SOIC, SSOP

Target Applications

• Memory address drivers in 5G base station controllers
• Bus interface for automotive dashboard display modules
• Data buffering in industrial PLC I/O modules
• Signal routing in telecom switching equipment
• Level translation in mixed-voltage systems
