SN74ACT8541QDGSRQ1 TI Buffer/Driver | 20-VSSOP | 8-bit, 3-State, Automotive

Product Overview

The SN74ACT8541QDGSRQ1 is a high-performance octal buffer and line driver from Texas Instruments, designed for automotive applications. It features 8-bit non-inverting outputs with 3-state capability, allowing for bus-oriented systems. The device operates over a wide voltage range of 4.5V to 5.5V and is characterized for operation from -40°C to +125°C, making it suitable for harsh automotive environments. Housed in a compact 20-VSSOP package, it offers high drive current (±24 mA at 5V) and fast propagation delays (typical 6.5 ns). The SN74ACT8541QDGSRQ1 is AEC-Q100 qualified and supports partial-power-down (Ioff) protection, preventing backflow current when the device is powered down.

Detailed Technical Specifications

Key Features

• 8-bit non-inverting buffer/line driver with 3-state outputs
• Wide operating voltage: 4.5V to 5.5V
• High drive capability: ±24 mA at 5V
• Fast propagation delay: 6.5 ns typical
• Partial-power-down (Ioff) protection
• AEC-Q100 qualified for automotive applications
• ESD protection: 2 kV HBM, 1 kV CDM
• Low power consumption: 40 µA max ICC
• Supports live insertion and withdrawal

Target Applications

• Automotive infotainment systems (e.g., Tesla Model S dashboard display interface)
• Advanced driver-assistance systems (ADAS) like Mobileye EyeQ5 camera modules
• 5G base station control boards (e.g., Nokia AirScale baseband units)
• Industrial motor drives (e.g., Siemens SINAMICS G120)
• Telecommunications equipment (e.g., Cisco ASR 9000 routers)

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for SN74ACT8541QDGSRQ1. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
