Product Overview
The SN74AUP2G80RSER is a dual positive-edge-triggered D-type flip-flop from Texas Instruments, designed for ultra-low-power applications. It operates over a wide supply voltage range of 0.8V to 3.6V, making it ideal for battery-powered and portable devices. The device features two independent flip-flops with a common clock (CLK) and clear (CLR) input. Each flip-flop stores the state of its D input at the rising edge of CLK, and the output (Q) reflects the stored data. The clear input resets the outputs to low (Q = 0) when active high. The SN74AUP2G80RSER is available in a compact 8-UQFN (1.5x1.5mm) package, saving board space.
Detailed Technical Specifications
| Parameter |
Value |
| Supply Voltage (VCC) |
0.8V to 3.6V |
| Input Voltage (VI) |
0V to 3.6V |
| Output Voltage (VO) |
0V to VCC |
| High-Level Input Voltage (VIH) |
0.65 × VCC (min) |
| Low-Level Input Voltage (VIL) |
0.35 × VCC (max) |
| High-Level Output Current (IOH) |
-4 mA at 3.0V |
| Low-Level Output Current (IOL) |
4 mA at 3.0V |
| Propagation Delay (tpd) |
4.3 ns (typ) at 3.3V |
| Input Capacitance (Ci) |
1.5 pF (typ) |
| Operating Temperature Range |
-40°C to +85°C |
| Package |
8-UQFN (1.5x1.5mm) |
Key Features
- Ultra-low power consumption: 0.9 µA max ICC at 25°C
- Wide supply voltage range: 0.8V to 3.6V
- High noise immunity: VIH = 0.65 × VCC, VIL = 0.35 × VCC
- Low propagation delay: 4.3 ns typical at 3.3V
- Input hysteresis for slow input signals
- Output drive: ±4 mA at 3.0V
- Latch-up performance exceeds 100 mA per JESD 78, Class II
- ESD protection: HBM 2000V, CDM 1000V
- Available in space-saving 8-UQFN package
Target Applications
- Portable and battery-powered electronics (e.g., smartphones, tablets)
- Wearable devices (e.g., smartwatches, fitness trackers)
- IoT sensors and edge nodes
- 5G base station control logic
- Automotive dashboard displays and infotainment systems
- Medical devices (e.g., portable monitors)
- Industrial automation and control systems
