SN74AVCA406DGG TI Bus Switch | 24-TSSOP | 2.3V-3.6V, 4-Bit, 1:2 MUX

Product Overview

The SN74AVCA406DGG from Texas Instruments is a 4-bit 1-of-2 multiplexer/demultiplexer bus switch designed for high-performance signal routing. It operates over a wide supply voltage range of 2.3V to 3.6V, making it suitable for low-voltage applications. The device features low ON-state resistance (5 Ω typical) and high bandwidth (up to 500 MHz), ensuring minimal signal distortion. Packaged in a 24-pin TSSOP, it supports bidirectional data flow with flow-through pinout for easy PCB layout.

Detailed Technical Specifications

Key Features

• 4-bit 1-of-2 multiplexer/demultiplexer bus switch
• Low ON-state resistance (5 Ω) for minimal signal attenuation
• High bandwidth (500 MHz) supports high-speed data signals
• Wide supply voltage range (2.3V to 3.6V) compatible with various logic families
• Flow-through pinout simplifies PCB routing
• Bidirectional data flow with no direction control required
• Low power consumption (ICC = 3 μA max)
• ESD protection exceeds JESD 22 standards

Target Applications

• 5G base station signal routing (e.g., antenna interface switching)
• Automotive dashboard display multiplexing (e.g., LVDS signal switching)
• Industrial automation I/O expansion (e.g., PLC module signal selection)
• Consumer electronics (e.g., smartphone audio path switching)
• Data communication (e.g., PCIe lane multiplexing)
