SN74CBT3384DW TI Bus Switch | 10-bit FET | 4.5-5.5V, 250MHz

Product Overview

The SN74CBT3384DW from Texas Instruments is a high-performance 10-bit FET bus switch designed for bus isolation and voltage translation in digital systems. It operates from a single 4.5V to 5.5V supply, providing bidirectional switching with low on-state resistance (5 Ω typical) and minimal propagation delay. The device features two 5-bit switch banks with independent output enable controls, making it ideal for multiplexing and bus isolation applications. Housed in a 24-pin SOIC (DW) package, it supports high-speed data rates up to 250 MHz and is characterized for operation from -40°C to +85°C.

Detailed Technical Specifications

Key Features

• Bidirectional FET switch with low 5 Ω on-resistance
• High bandwidth up to 250 MHz for fast data switching
• Ultra-low propagation delay (0.25 ns) for signal integrity
• Two independent 5-bit switch banks with separate enables
• 5V tolerant I/Os with TTL-compatible control inputs
• Low power consumption (ICC max 3 μA)
• ESD protection exceeds 2000V HBM

Target Applications

• Bus isolation in 5G base station control boards
• Signal multiplexing in automotive dashboard displays
• Voltage level translation in industrial PLC modules
• Memory card interface switching in consumer electronics
• Hot-swap and power sequencing in server motherboards
