SN74GTL2006PWR TI Voltage Level Translator | 28-TSSOP | 8-Bit, 100Mbps

Product Overview

The SN74GTL2006PWR is a high-performance 8-bit voltage level translator from Texas Instruments, designed to interface between GTL (Gunning Transceiver Logic) and LVTTL (Low-Voltage TTL) logic levels. Housed in a compact 28-TSSOP package, this device supports bidirectional translation with data rates up to 100 Mbps, making it ideal for high-speed digital systems. It operates over a wide supply voltage range (1.65V to 3.6V on the LVTTL side and 1.0V to 3.6V on the GTL side), ensuring compatibility with various logic families. The SN74GTL2006PWR features flow-through pinout for easy PCB layout and is characterized for operation from -40°C to +85°C.

Detailed Technical Specifications

Key Features

• Bidirectional voltage translation between GTL and LVTTL
• High data rate up to 100 Mbps
• Wide supply voltage range for flexible system integration
• Flow-through pinout simplifies PCB routing
• Low propagation delay (3.5 ns typical)
• High output drive capability (±24 mA)
• ESD protection exceeds 2000V HBM

Target Applications

• 5G base station control logic interfacing
• Automotive dashboard display modules
• Industrial automation PLCs
• Networking equipment (routers, switches)
• FPGA/ASIC voltage level translation
• Memory interface (DDR, SRAM)

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for SN74GTL2006PWR. Our core advantages include:

• 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
• In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
• HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
• Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
• BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

• 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
• RoHS Compliant: All electronic components comply with international environmental and safety standards.
• Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
