SN74HC367NSR TI Buffer/Line Driver | 16-SO | 6-Channel, Non-Inverting, 2V-6V

QUOTE REQ
×

WECHAT SUPPORT

Direct Engineer Contact

WeChat QR

ID: Jasin_Semi

HK/SZ Authorized Supply

×

ENTERPRISE QQ

Fast Quotation

QQ QR

Official ID: 4008823823

×

TELEGRAM SUPPORT

Global & CIS Region Support

Telegram QR

@你的Telegram用户名

STM32F103C8T6NE555PLM358DRESP32-WROOM-32TL431AIDBZRAMS1117-3.3LM7805MAX3232CSEPC817CTPS5430DDAR STM32F103C8T6NE555PLM358DRESP32-WROOM-32TL431AIDBZRAMS1117-3.3LM7805MAX3232CSEPC817CTPS5430DDAR
1N40072N2222IRFZ44NFGA25N120S8050M7(1N4007)SS14TIP122AO3400IKW40N120H3 1N40072N2222IRFZ44NFGA25N120S8050M7(1N4007)SS14TIP122AO3400IKW40N120H3
ATMEGA328P-AUESP8266-12ELM2596S-ADJBC547BIRLZ44NMCP2515-I/STSN65HVD230AD8232L293DTDA7297 ATMEGA328P-AUESP8266-12ELM2596S-ADJBC547BIRLZ44NMCP2515-I/STSN65HVD230AD8232L293DTDA7297
产品描述
🧪 SAMPLE SUPPORT ✅ 100% Original & Traceable 🚀 Inquiry Today, Ship Today 🛡️ Escrow.com Secured Payment

Product Overview

The SN74HC367NSR from Texas Instruments is a high-speed, 6-channel non-inverting buffer/line driver with 3-state outputs. It is designed for use in systems requiring high drive capability and low power consumption. The device operates over a wide voltage range of 2V to 6V, making it suitable for interfacing with various logic families. The 3-state outputs allow for bus-oriented applications, enabling multiple outputs to share a common bus line. The SN74HC367NSR is housed in a 16-pin SO package, offering a compact solution for space-constrained designs.

Detailed Technical Specifications

Parameter Value
Supply Voltage (VCC) 2V to 6V
Input Voltage (VI) 0V to VCC
Output Voltage (VO) 0V to VCC
High-Level Output Current (IOH) -6 mA at VCC = 4.5V
Low-Level Output Current (IOL) 6 mA at VCC = 4.5V
Propagation Delay (tpd) 12 ns typical at VCC = 5V, CL = 50 pF
Input Capacitance (Ci) 3 pF typical
Operating Temperature Range -40°C to +85°C
Package 16-SO (NSR suffix)

Key Features

  • 6 non-inverting buffers with 3-state outputs
  • Wide operating voltage range: 2V to 6V
  • High drive capability: ±6 mA at 5V
  • Low power consumption: ICC max 80 µA
  • Fast propagation delay: 12 ns typical at 5V
  • Inputs are TTL-voltage compatible
  • Outputs can be connected directly to bus lines
  • ESD protection exceeds 2000V per MIL-STD-883, Method 3015

Target Applications

  • 5G base station control logic: buffering signals between FPGA and RF modules
  • Automotive dashboard display: driving LED indicators and segment displays
  • Industrial PLC I/O modules: isolating and buffering sensor signals
  • Consumer electronics: level shifting for memory interfaces
  • Telecommunications: line driving for backplane buses

Global Supply Chain & Wholesale Solutions

At Jasin Chip, we provide professional supply chain and wholesale solutions for SN74HC367NSR. Our core advantages include:

  • 24/7 Global Customer Support: Professional team providing instant quotes and technical support worldwide.
  • In-stock Inventory, Same-day Shipping: We maintain localized stock; orders confirmed before 4 PM are shipped the same day.
  • HK-SZ Synergy, Flexible Settlement: Direct global shipping from Shenzhen with support for HK bank transfers and multi-currency.
  • Escrow Secured Transactions: We support Escrow.com for secure transactions, ensuring peace of mind for batch orders.
  • BOM Kitting & Sampling Services: Specialized sourcing for testing samples and urgent shortage components.

Quality Assurance & Compliance

Jasin Chip guarantees that all delivered products are 100% original factory stock with full quality assurance and traceability.

  • 100% Original & Authentic: All components are guaranteed to be authentic with strict quality control.
  • RoHS Compliant: All electronic components comply with international environmental and safety standards.
  • Original Factory Packaging: We maintain original factory packaging and seals to ensure ESD protection and physical integrity.
